New Holland 1920
| | 1996 - 2000 |
| Twenty Compact Series | | Compact Utility tractor | | Shibaura built |
|
Series map:
1720
1920
2120
27.7hp
33.3hp
42.6hp
Note: the New Holland model 1920 is the same as the Ford 1920. The following data is from the 1920 listing. |
| Production |
| Distributor | New Holland
|
| Manufacturer | Shibaura
|
| Compact Utility tractor |
| Built in Japan |
| Original price was $15,500 in 2000 |
| New Holland 1920 Power |
| Engine (gross) | 33.3 hp
24.8 kW
|
| Engine (net) | 32 hp
23.9 kW
|
| PTO (claimed) | 28.5 hp
21.3 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Wet disc brakes |
| Two-post ROPS. |
| Capacity |
| Fuel | 9.8 gal
37.1 L
|
| Hydraulic system | 7.7 gal
29.1 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 7.7 gal
29.1 L
|
| Pump flow | 7.8 gpm
29.5 lpm
|
| Total flow | 10.6 gpm
40.1 lpm
|
| Steering flow | 2.8 gpm
10.6 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | draft control OptOptional
|
| Rear lift (at 24"/610mm) | 1881 lbs
853 kg
|
| Power Take-off (PTO) |
| Rear PTO | transmission
|
| | live OptOptional
|
| Rear PTO Type | 540
|
| 1920 Serial Numbers |
| Location: | transmission, left side
|
| 1987 | UP21001
|
| 1988 | UP21710
|
| 1989 | UP24896
|
| 1990 | UP27299
|
| 1991 | UP29354
|
| 1992 | UP30817
|
| 1993 | UP32448
|
| 1994 | UP34038
|
| 1995 | UP35988
|
| 1996 | UP37672
|
| 1997 | UP39076
|
| 1998 | UP41105
|
| 1999 | UP43277
|
| 2000 | UP45272
|
FAQ: How to read a serial number table.
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| Compact Diesel Tractors published in 1996, by New Holland |
| North American Buyer's Guide published in 1997, by New Holland |
©2000-2024 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
