J.I. Case 3294
|
|
| Production | |
| Manufacturer | J.I. Case |
| Row-Crop tractor | |
| Built in Racine, Wisconsin, USA | |
| Original price | $67,600 (1984) |
| J.I. Case 3294 Engine | |
| Case 8.3L 6-cyl diesel | |
 Engine details ... |
| J.I. Case 3294 Transmission | |
| 12-speed three-speed power shift | |
 Transmission details ... |
| J.I. Case 3294 Power | |
| Engine | 197 hp 146.9 kW |
| Drawbar (claimed) | 143 hp 106.6 kW |
| PTO (claimed) | 162 hp 120.8 kW |
| Drawbar (tested) | 140.79 hp 105.0 kW |
| PTO (tested) | 162.63 hp 121.3 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Silent Guardian cab with air-conditioning. |
| Photos | |
| No photos of the J.I. Case 3294 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 65 gal 246.0 L |
| 25 gal (optional auxiliary tank) 94.6 L | |
| Hydraulic system | 32 gal 121.1 L |
| Hydraulics | |
| Type | closed center |
| Capacity | 32 gal 121.1 L |
| Pressure | 2250 psi 155.1 bar |
| Valves | 2 to 4 |
| Pump flow | 23 gpm 87.1 lpm |
| Steering flow | 8 gpm 30.3 lpm |
| Steering press. | 2000 psi 137.9 bar |
| Tractor hitch | |
| Rear Type | 3/2 |
| Rear lift (at 24"/610mm) | 6,600 lbs 2993 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 104 inches 264 cm |
| Weight | 17,000 lbs 7711 kg |
| Front tire | 11.00x16 |
| Rear tire | 18.4x38 |
 Full dimensions and tires ... | |
| 3294 Serial Numbers | |
| Location: | Inside cab or on right-front frame |
| 1984 | 9932190 |
| 1985 | 9938125 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 72 |
| 105 OptOptional | |
| Battery volts | 12 |
| References | |
 | |
| Product Information - Case 94 Series Tractors published in 1983, by J.I. Case | |
| The Tractor Specialist Buyers Guide published in 1984, by J.I. Case | |
| Tractor & Loaders Buyers Guide published in 1985, by J.I. Case |
