J.I. Case 1290 Tests


J.I. Case 1290 tractor photo
1980 - 1983
90 Series
Utility tractor
Series map:
1190
1290
1390
47.8hp*
58.9hp*
66.7hp*
*Estimated engine power for comparison only.
Nebraska Tractor Test 1379
1290 fuel use from test 1379
Nebraska Tractor Test 1379
Diesel 12-speed 4WD
March 18 - April 13, 1981
Link: Nebraska Tractor Test 1379 file
PTO performance
Power at rated engine speed53.73 hp
40.1 kW
Fuel use3.6 gal/hour
13.6 l/hour
Power at rated PTO speed47.80 hp
35.6 kW
Fuel use3.1 gal/hour
11.7 l/hour
Drawbar performance
Max power44.81 hp
33.4 kW
Fuel use3.5 gal/hour
13.2 l/hour
Gear 4-1 used for power test.
Max pull8445 lbs
3830 kg
Gear 2-1 used for pull test.
