J.I. Case 570 Tests


J.I. Case 570 tractor photo
1970 - 1973
Series map:
470
570
37.8hp*
43.9hp*
*Estimated engine power for comparison only.
Tractor Tests
NTTL 771: gasoline 12-speed 2WD
NTTL 772: diesel 12-speed 2WD
Nebraska Tractor Test 771
570 fuel use from test 771
Nebraska Tractor Test 771
Gasoline 12-speed 2WD
October 11 - 27, 1960
Link: Nebraska Tractor Test 771 file
PTO performance
Power at rated engine speed39.50 hp
29.5 kW
Fuel use3.3 gal/hour
12.5 l/hour
Power at rated PTO speed38.22 hp
28.5 kW
Fuel use3.1 gal/hour
11.7 l/hour
Drawbar performance
Max power32.85 hp
24.5 kW
Fuel use3.2 gal/hour
12.1 l/hour
Gear 5 used for power test.
Max pull5,834 lbs
2646 kg
Gear 1 used for pull test.
Nebraska Tractor Test 772
570 fuel use from test 772
Nebraska Tractor Test 772
Diesel 12-speed 2WD
October 12 - 27, 1960
Link: Nebraska Tractor Test 772 file
PTO performance
Power at rated engine speed41.27 hp
30.8 kW
Fuel use2.5 gal/hour
9.5 l/hour
Power at rated PTO speed39.41 hp
29.4 kW
Fuel use2.4 gal/hour
9.1 l/hour
Drawbar performance
Max power37.03 hp
27.6 kW
Fuel use2.4 gal/hour
9.1 l/hour
Gear 5 used for power test.
Max pull6,124 lbs
2777 kg
Gear 1 used for pull test.
