J.I. Case 401


J.I. Case 401 tractor photo
1955 - 1957
400 Series
Row-Crop tractor
Series map:
401
55.6hp*
*Estimated engine power for comparison only.
Production
ManufacturerJ.I. Case
Row-Crop tractor
Built in Racine, Wisconsin, USA
Total built5,696
Original price$4,300 (1958)
The J.I. Case 401 is the diesel row-crop model of the Case 400 tractor series. The 401 was available with a single front wheel, dual (tricycle style) front wheels, and an adjustable wide front axle.
Variants
400diesel standard
401diesel row-crop
402diesel vineyard
403diesel high-crop
405diesel orchard
411gasoline row-crop
420diesel industrial
J.I. Case 401 Engine
J.I. Case 4.1L 4-cyl diesel
Engine details ...
J.I. Case 401 Power
Belt (claimed)50 hp
37.3 kW
Plows4 (14-inch)
Drawbar (tested)33.47 hp
25.0 kW
Belt (tested)49.40 hp
36.8 kW
Performance test details ...
Mechanical
Two-wheel drive
Steeringmanual
 power optional
Differential mechanical dry discs brakes
Open opertator station.
Capacity
Fuel21 gal
79.5 L
Hydraulic system2.25 gal
8.5 L
 2.6 gal (with Eagle Hitch)
9.8 L
Steering3.75 qts
3.5 L
Hydraulics
Capacity2.25 gal
8.5 L
 2.6 gal (with Eagle Hitch)
9.8 L
Pressure600 psi
41.4 bar
Valves2 (optional)
Total flow12 gpm
45.4 lpm
Steering cap.3.75 qts
3.5 L
Tractor hitch
TypeCase Eagle Hitch
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Dimensions & Tires
Wheelbase91.5 inches (tricycle)
232 cm
 101 inches (wide front)
256 cm
Weight5850 to 6390 pounds
Front tire6.00-16
Rear tire12-38
Full dimensions and tires ...
401 Serial Number Location
J.I. Case 401 serial number location
Top-right of instrument panel.
401 Serial Numbers
19558060000
19568080001
19578100001

FAQ: How to read a serial number table.
Belt Pulley
Diameter10.5 inches
26 cm
Width7.25 inches
18 cm
RPM1128
Speed3101 ft/min
945.18 meters/min
Electrical
Groundnegative
Charging systemgenerator
Charging volts12
Batteries2
Battery volts6
Battery AH150
References
401 references literature
All New "400" published in 1955, by J.I. Case
Operator's Instruction Manual 400 Series Diesel Tractors (5688) published in 1954
Dealer's Service Manual "400" Series Tractors and Engines (5692) published in 1955
