J.I. Case 311 Transmission


J.I. Case 311 tractor photo
1956 - 1958
300 Series
Row-Crop tractor
Series map:
311
32.2hp*
*Estimated engine power for comparison only.
Transmission options
4-speed sliding gear
12-speed
Transmission
Typesliding gear
Gears4 forward and 1 reverse
Clutch234.9mm dry disc
Speeds
311  sliding gear speeds
Transmission
TransmissionTripl-Range
Gears12 forward and 3 reverse
Clutch234.9mm dry disc (master foot clutch)
 wet discs (traction hand clutch)
Four gears (1-4) plus reverse (R) in three ranges (low, direct, high).
Speeds
311 Tripl-Range  speeds
J.I. Case 311 Transmission
J.I. Case 311 transmission image
