Tractors > J.I. Case > L

J.I. Case L Tests



J.I. Case L tractor photo
1929 - 1940
Standard-tread tractor
Series map:
L
50.0hp*
*Estimated engine power for comparison only.
Nebraska Tractor Test 309
L fuel use from test 309
Nebraska Tractor Test 309
Gasoline 3-speed 2WD
October 10 - 24, 1938
Link: Nebraska Tractor Test 309 file
Belt power (max)47.04 hp
35.1 kW
Belt fuel use (max)4.5 gal/hour
17.0 l/hour
Drawbar performance
Max power40.80 hp
30.4 kW
Gear 2 used for power test.
Max pull4,474 lbs
2029 kg
Gear 1 used for pull test.
