Production | |
Manufacturer | International Harvester |
Utility tractor | |
Built in Rock Island, Illinois, USA | |
Original price was $7,500 in 1973 |
International Harvester 664 Engine | |
International Harvester 3.9L 4-cyl diesel | |
Fuel tank | 17.5 gal 66.2 L |
Engine details ... |
International Harvester 664 Transmissions | |
10-speed two-speed power shift | |
5-speed gear | |
Transmission details ... |
International Harvester 664 Power | |
Drawbar (claimed) | 54 hp 40.3 kW |
PTO (claimed) | 62 hp 46.2 kW |
Mechanical | |
Two-wheel drive | |
Final drives | bull gear |
Power steering | |
Mechanical disc brakes | |
Open operator station. |
Hydraulics | |
Type | open center |
Pump flow | 12 gpm 45.4 lpm |
Tractor hitch | |
Rear Type | II |
Control | draft control |
Power Take-off (PTO) | |
Rear PTO | independent |
Clutch | hydrauilc disc |
Rear PTO Type | 540 (1.375) |
  | 1000 (1.375) |
Engine RPM | 540@2000 |
  | 1000@2240 |
Dimensions & Tires | |
Wheelbase | 74 inches 187 cm |
Weight | 5950 lbs 2698 kg |
Front tire | 6.50-16 |
Rear tire | 14.9-30 |
Full dimensions and tires ... |
664 Serial Numbers | |
1972 | 2501 |
1973 | 3212 |
FAQ: How to read a serial number table. |
Electrical | |
Charging system | alternator |
Charging amps | 32 |
Batteries | 2 |
Battery volts | 6 |
Battery AH | 135 |
References | |
Farm Equipment Reference Catalog published in 1972, by International Harvester |
