| | 1970 - 1978 |
| Utility tractor |
|
Series map:
464
574
674
48.9hp*
67.0hp
65.0hp*
*Estimated engine power for comparison only.
| Transmission options |
| 8-speed partially synchronized |
| hydrostatic |
| 16-speed two-speed power shift. |
| Transmission |
| Type | partially synchronized
|
| Gears | 8 forward and 4 reverse
|
| Clutch | 280mm dry disc
|
| Four synchronized gears (1-4) in low, high, and reverse ranges. |
| Speeds |
|
| Transmission |
| Type | hydrostatic
|
| Gears | infinite forward and reverse
|
| The hydrostatic model 574 was uncommon in North America, most were sold in the European market. |
| Speeds |
|
| Transmission |
| Transmission | Torque Amplifier
|
| Type | two-speed power shift.
|
| Gears | 16 forward and 8 reverse
|
| Speeds |
| With 16.9x30 rear tires. |
|
