International Harvester 350 Tests
|
|
| Tractor Tests | |
| NTTL 610: diesel Torque Amplifier 2WD | |
| NTTL 615: gasoline Torque Amplifier 2WD | |
| NTTL 619: LP gas Torque Amplifier 2WD |
| Nebraska Tractor Test 610 | |||
| |||
| Nebraska Tractor Test 610 | |
| Diesel Torque Amplifier 2WD March 26 - April 15, 1957 Link: Nebraska Tractor Test 610 file | |
| Belt power (max) | 42.89 hp 32.0 kW |
| Belt fuel use (max) | 3.1 gal/hour 11.7 l/hour |
| Drawbar performance | |
| Max power | 31.15 hp 23.2 kW |
| Fuel use | 2.5 gal/hour 9.5 l/hour |
| Gear 3 used for power test. | |
| Max pull | 5,862 lbs 2659 kg |
| Gear 1 used for pull test. | |
| Nebraska Tractor Test 615 | |||
| |||
| Nebraska Tractor Test 615 | |
| Gasoline Torque Amplifier 2WD April 24 - May 1, 1957 Link: Nebraska Tractor Test 615 file | |
| Belt power (max) | 43.32 hp 32.3 kW |
| Belt fuel use (max) | 3.9 gal/hour 14.8 l/hour |
| Drawbar performance | |
| Max power | 31.24 hp 23.3 kW |
| Fuel use | 3.3 gal/hour 12.5 l/hour |
| Gear 3 used for power test. | |
| Max pull | 6,029 lbs 2734 kg |
| Gear 1-TA used for pull test. | |
| Nebraska Tractor Test 619 | |||
| |||
| Nebraska Tractor Test 619 | |
| LP gas Torque Amplifier 2WD May 7 - 28, 1957 Link: Nebraska Tractor Test 619 file | |
| Belt power (max) | 45.24 hp 33.7 kW |
| Belt fuel use (max) | 5.0 gal/hour 18.9 l/hour |
| Drawbar performance | |
| Max power | 32.74 hp 24.4 kW |
| Fuel use | 3.9 gal/hour 14.8 l/hour |
| Gear 3 used for power test. | |
| Max pull | 6,357 lbs 2883 kg |
| Gear 1-TA used for pull test. | |
