Ford 9600
|
|
| Production | |
| Manufacturer | Ford |
| Row-Crop tractor | |
| Built in Romeo, Michigan, USA | |
| Original price was $17,300 in 1976 | |
| Ford 9600 Engine | |
| Ford 6.6L 6-cyl diesel | |
 Engine details ... |
| Ford 9600 Transmissions | |
| 16-speed partial power shift | |
| 8-speed | |
 Transmission details ... |
| Ford 9600 Power | |
| Drawbar (tested) | 111.40 hp 83.1 kW |
| PTO (tested) | 135.46 hp 101.0 kW |
 Performance test details ... | |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Differential hydraulic wet disc brakes | |
| Open operator station. Cab optional. | |
| Photos | |
 | |
 Ford 9600 photos... | |
| Capacity | |
| Fuel | 43 gal 162.8 L |
| Hydraulic system | 16 gal 60.6 L |
| 17.25 gal (Dual Power) 65.3 L | |
| Steering | 3 qts 2.8 L |
| Hydraulics | |
| Capacity | 16 gal 60.6 L |
| 17.25 gal (Dual Power) 65.3 L | |
| Pressure | 2500 psi 172.4 bar |
| Pump flow | 16 gpm 60.6 lpm |
| Steering flow | 4.2 gpm 15.9 lpm |
| Steering cap. | 3 qts 2.8 L |
| Steering press. | 1500 psi 103.4 bar |
| Tractor hitch | |
| Rear Type | III/II |
| Rear lift | 18000 lbs 8164 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 |
| Engine RPM | 1000@1935 |
| Dimensions & Tires | |
| Wheelbase | 91.5 inches 232 cm |
| 108 inches (row-crop) 274 cm | |
| Weight | 11,860 lbs 5379 kg |
| Front tire | 7.50-18 |
| Rear tire | 23.1-34 |
 Full dimensions and tires ... | |
| 9600 Serial Numbers | |
| 1972 | C327200 |
| 1973 | C367300 |
| 1974 | C405200 |
| 1975 | C450700 |
| 1976 | C490300 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 55 |
| Battery volts | 12 |
| Battery AH | 128 |
| References | |
 | |
| Buyer's Guide '74 published in 1974, by Ford | |
| 8000, 8600, 9000 and 9600 Repair Time Schedule (SE 3410) published in 1973 | |
| 9600 Operator's Manual (SE 3378) published in 1972 |
