Ford 7000 Engine


Ford 7000 tractor photo
1971 - 1975
Utility tractor
Series map:
7000
93.0hp
Engine Detail
Ford
turbocharged diesel
4-cylinder
liquid-cooled
Displacement256 ci
4.2 L
Bore/Stroke4.40x4.20 inches
112 x 107 mm
Power (net)89 hp
66.4 kW
Power (gross)93 hp
69.4 kW
Air cleanerdry
Compression16.5:1
Rated RPM2100
Firing order1-3-4-2
Starter volts12
Coolant capacity14.5 qts
13.7 L
Intake valve clearance0.015 inches (hot)
0.381 mm
Exhaust valve clearance0.018 inches (hot)
0.457 mm
Engine Oil
7000 diesel engine oil chart
Oil capacity9 qts
8.5 L
