Ford 5000 Tests
|
|
| Tractor Tests | |
| NTTL 879: diesel 8-speed 2WD | |
| NTTL 880: diesel Select-O-Speed 2WD | |
| NTTL 932: gasoline 8-speed 2WD | |
| NTTL 933: gasoline Select-O-Speed 2WD |
| Nebraska Tractor Test 879 | |||
| |||
| Nebraska Tractor Test 879 | |
| Diesel 8-speed 2WD March 16 - April 9, 1965 Link: Nebraska Tractor Test 879 file | |
| PTO performance | |
| Power at rated engine speed | 55.96 hp 41.7 kW |
| Fuel use | 3.6 gal/hour 13.6 l/hour |
| Power at rated PTO speed | 53.30 hp 39.7 kW |
| Fuel use | 3.2 gal/hour 12.1 l/hour |
| Drawbar performance | |
| Max power | 47.65 hp 35.5 kW |
| Fuel use | 3.6 gal/hour 13.6 l/hour |
| Gear 4 used for power test. | |
| Max pull | 6,991 lbs 3171 kg |
| Gear 2 used for pull test. | |
| Nebraska Tractor Test 880 | |||
| |||
| Nebraska Tractor Test 880 | |
| Diesel Select-O-Speed 2WD March 18 - April 10, 1965 Link: Nebraska Tractor Test 880 file | |
| PTO performance | |
| Power at rated engine speed | 54.17 hp 40.4 kW |
| Fuel use | 3.5 gal/hour 13.2 l/hour |
| Power at rated PTO speed | 51.49 hp 38.4 kW |
| Fuel use | 3.2 gal/hour 12.1 l/hour |
| Drawbar performance | |
| Max power | 45.32 hp 33.8 kW |
| Fuel use | 3.5 gal/hour 13.2 l/hour |
| Gear 6 used for power test. | |
| Max pull | 6973 lbs 3162 kg |
| Gear 4 used for pull test. | |
| Nebraska Tractor Test 932 | |||
| |||
| Nebraska Tractor Test 932 | |
| Gasoline 8-speed 2WD April 13 - 21, 1966 Link: Nebraska Tractor Test 932 file | |
| PTO performance | |
| Power at rated engine speed | 60.37 hp 45.0 kW |
| Fuel use | 5.1 gal/hour 19.3 l/hour |
| Power at rated PTO speed | 56.94 hp 42.5 kW |
| Fuel use | 4.8 gal/hour 18.2 l/hour |
| Drawbar performance | |
| Max power | 50.85 hp 37.9 kW |
| Fuel use | 5.0 gal/hour 18.9 l/hour |
| Gear 4 used for power test. | |
| Max pull | 7,084 lbs 3213 kg |
| Gear 2 used for pull test. | |
| Nebraska Tractor Test 933 | |||
| |||
| Nebraska Tractor Test 933 | |
| Gasoline Select-O-Speed 2WD April 13 - 22, 1966 Link: Nebraska Tractor Test 933 file | |
| PTO performance | |
| Power at rated engine speed | 58.49 hp 43.6 kW |
| Fuel use | 5.0 gal/hour 18.9 l/hour |
| Power at rated PTO speed | 55.33 hp 41.3 kW |
| Fuel use | 4.7 gal/hour 17.8 l/hour |
| Drawbar performance | |
| Max power | 49.51 hp 36.9 kW |
| Fuel use | 5.0 gal/hour 18.9 l/hour |
| Gear 6 used for power test. | |
| Max pull | 7073 lbs 3208 kg |
| Gear 4 used for pull test. | |
