Ford 3600 Tests
|
|
| Tractor Tests | |
| NTTL 1203: diesel 6 speed 2WD | |
| NTTL 1208: gasoline 6 speed 2WD | |
| NTTL 1221: diesel 8 speed 2WD | |
| NTTL 1226: gasoline 8 speed 2WD |
| Nebraska Tractor Test 1203 | |||
| |||
| Nebraska Tractor Test 1203 | |
| Diesel 6 speed 2WD March 16 - April 7, 1976 Link: Nebraska Tractor Test 1203 file | |
| PTO performance | |
| Power at rated engine speed | 40.49 hp 30.2 kW |
| Fuel use | 2.7 gal/hour 10.2 l/hour |
| Power at rated PTO speed | 37.64 hp 28.1 kW |
| Fuel use | 2.5 gal/hour 9.5 l/hour |
| Drawbar performance | |
| Max power | 33.79 hp 25.2 kW |
| Fuel use | 2.6 gal/hour 9.8 l/hour |
| Gear 3 used for power test. | |
| Max pull | 5,114 lbs 2319 kg |
| Gear 1 used for pull test. | |
| Nebraska Tractor Test 1208 | |||
| |||
| Nebraska Tractor Test 1208 | |
| Gasoline 6 speed 2WD March 25 - April 21, 1976 Link: Nebraska Tractor Test 1208 file | |
| PTO performance | |
| Power at rated engine speed | 40.17 hp 30.0 kW |
| Fuel use | 3.8 gal/hour 14.4 l/hour |
| Power at rated PTO speed | 37.91 hp 28.3 kW |
| Fuel use | 3.4 gal/hour 12.9 l/hour |
| Drawbar performance | |
| Max power | 34.35 hp 25.6 kW |
| Fuel use | 3.7 gal/hour 14.0 l/hour |
| Gear 3 used for power test. | |
| Max pull | 5,158 lbs 2339 kg |
| Gear 2 used for pull test. | |
| Nebraska Tractor Test 1221 | |||
| |||
| Nebraska Tractor Test 1221 | |
| Diesel 8 speed 2WD September 28 - October 9, 1976 Link: Nebraska Tractor Test 1221 file | |
| PTO performance | |
| Power at rated engine speed | 40.55 hp 30.2 kW |
| Fuel use | 2.7 gal/hour 10.2 l/hour |
| Power at rated PTO speed | 38.31 hp 28.6 kW |
| Fuel use | 2.5 gal/hour 9.5 l/hour |
| Drawbar performance | |
| Max power | 33.71 hp 25.1 kW |
| Fuel use | 2.6 gal/hour 9.8 l/hour |
| Gear 4 used for power test. | |
| Max pull | 5,277 lbs 2393 kg |
| Gear 2 used for pull test. | |
| Nebraska Tractor Test 1226 | |||
| |||
| Nebraska Tractor Test 1226 | |
| Gasoline 8 speed 2WD September 23 - October 14, 1976 Link: Nebraska Tractor Test 1226 file | |
| PTO performance | |
| Power at rated engine speed | 40.62 hp 30.3 kW |
| Fuel use | 3.8 gal/hour 14.4 l/hour |
| Power at rated PTO speed | 38.29 hp 28.6 kW |
| Fuel use | 3.4 gal/hour 12.9 l/hour |
| Drawbar performance | |
| Max power | 33.80 hp 25.2 kW |
| Fuel use | 3.7 gal/hour 14.0 l/hour |
| Gear 4 used for power test. | |
| Max pull | 5,123 lbs 2323 kg |
| Gear 2 used for pull test. | |
