Tractors > Ford > 3000

Ford 3000 Tests

1965 - 1975

Utility tractor

Series map:

3600↑ 1975-1981

2000

3000

36.0hp

46.7hp

Tractor Tests
NTTL 881: diesel 8-speed 2WD
NTTL 882: diesel Select-O-Speed 2WD
NTTL 883: diesel 12-speed 2WD
NTTL 885: gasoline Select-O-Speed 2WD
NTTL 888: gasoline 8-speed 2WD
NTTL 889: gasoline 12-speed 2WD
NTTL 1051: gasoline 6-speed 2WD
NTTL 1052: diesel 6-speed 2WD

Nebraska Tractor Test 881

Nebraska Tractor Test 881
Diesel 8-speed 2WD March 29 - April 6, 1965 Link: Nebraska Tractor Test 881 file
PTO performance
Power at rated engine speed	39.20 hp 29.2 kW
Fuel use	2.4 gal/hour 9.1 l/hour
Power at rated PTO speed	37.34 hp 27.8 kW
Fuel use	2.2 gal/hour 8.3 l/hour
Drawbar performance
Max power	34.88 hp 26.0 kW
Fuel use	2.5 gal/hour 9.5 l/hour
Gear 4 used for power test.
Max pull	5,106 lbs 2316 kg
Gear 2 used for pull test.

Nebraska Tractor Test 882

Nebraska Tractor Test 882
Diesel Select-O-Speed 2WD March 24 - April 9, 1965 Link: Nebraska Tractor Test 882 file
PTO performance
Power at rated engine speed	38.08 hp 28.4 kW
Fuel use	2.5 gal/hour 9.5 l/hour
Power at rated PTO speed	37.85 hp 28.2 kW
Fuel use	2.5 gal/hour 9.5 l/hour
Drawbar performance
Max power	30.60 hp 22.8 kW
Fuel use	2.5 gal/hour 9.5 l/hour
Gear 5 used for power test.
Max pull	5,016 lbs 2275 kg
Gear 4 used for pull test.

Nebraska Tractor Test 883

Nebraska Tractor Test 883
Diesel 12-speed 2WD March 27 - April 7, 1965 Link: Nebraska Tractor Test 883 file
PTO performance
Power at rated engine speed	39.46 hp 29.4 kW
Fuel use	2.5 gal/hour 9.5 l/hour
Power at rated PTO speed	31.81 hp 23.7 kW
Fuel use	1.9 gal/hour 7.2 l/hour
Drawbar performance
Max power	35.43 hp 26.4 kW
Fuel use	2.6 gal/hour 9.8 l/hour
Gear 2D used for power test.
Max pull	4,629 lbs 2099 kg
Gear 1U used for pull test.

Nebraska Tractor Test 885

Nebraska Tractor Test 885
Gasoline Select-O-Speed 2WD April 8 - 26, 1965 Link: Nebraska Tractor Test 885 file
PTO performance
Power at rated engine speed	36.49 hp 27.2 kW
Fuel use	3.3 gal/hour 12.5 l/hour
Power at rated PTO speed	35.30 hp 26.3 kW
Fuel use	3.2 gal/hour 12.1 l/hour
Drawbar performance
Max power	29.76 hp 22.2 kW
Fuel use	3.1 gal/hour 11.7 l/hour
Gear 6 used for power test.
Max pull	5,019 lbs 2276 kg
Gear 3 used for pull test.

Nebraska Tractor Test 888

Nebraska Tractor Test 888
Gasoline 8-speed 2WD April 20 - 27, 1965 Link: Nebraska Tractor Test 888 file
PTO performance
Power at rated engine speed	37.84 hp 28.2 kW
Fuel use	3.3 gal/hour 12.5 l/hour
Power at rated PTO speed	34.62 hp 25.8 kW
Fuel use	2.9 gal/hour 11.0 l/hour
Drawbar performance
Max power	32.52 hp 24.3 kW
Fuel use	3.3 gal/hour 12.5 l/hour
Gear 4 used for power test.
Max pull	5,059 lbs 2294 kg
Gear 2 used for pull test.

Nebraska Tractor Test 889

Nebraska Tractor Test 889
Gasoline 12-speed 2WD April 20 - May 6, 1965 Link: Nebraska Tractor Test 889 file
PTO performance
Power at rated engine speed	39.17 hp 29.2 kW
Fuel use	3.3 gal/hour 12.5 l/hour
Power at rated PTO speed	30.64 hp 22.8 kW
Fuel use	2.5 gal/hour 9.5 l/hour
Drawbar performance
Max power	33.04 hp 24.6 kW
Fuel use	3.3 gal/hour 12.5 l/hour
Gear 2D used for power test.
Max pull	4,622 lbs 2096 kg
Gear 1U used for pull test.

Nebraska Tractor Test 1051

Nebraska Tractor Test 1051
Gasoline 6-speed 2WD September 29 - October 5, 1970 Link: Nebraska Tractor Test 1051 file
PTO performance
Power at rated engine speed	38.33 hp 28.6 kW
Fuel use	3.5 gal/hour 13.2 l/hour
Power at rated PTO speed	34.34 hp 25.6 kW
Fuel use	3.1 gal/hour 11.7 l/hour
Drawbar performance
Max power	31.15 hp 23.2 kW
Fuel use	3.4 gal/hour 12.9 l/hour
Gear 3 used for power test.
Max pull	5,109 lbs 2317 kg
Gear 1 used for pull test.

Nebraska Tractor Test 1052

Nebraska Tractor Test 1052
Diesel 6-speed 2WD September 28 - October 14, 1970 Link: Nebraska Tractor Test 1052 file
PTO performance
Power at rated engine speed	40.63 hp 30.3 kW
Fuel use	2.6 gal/hour 9.8 l/hour
Power at rated PTO speed	39.07 hp 29.1 kW
Fuel use	2.5 gal/hour 9.5 l/hour
Drawbar performance
Max power	34.96 hp 26.1 kW
Fuel use	2.6 gal/hour 9.8 l/hour
Gear 3 used for power test.
Max pull	5,208 lbs 2362 kg
Gear 2 used for pull test.
