Ford 1710 Tests
|
|
| Tractor Tests | |
| NTTL 1502: diesel 12/4 gear 2WD | |
| NTTL 1503: diesel 12/4 synchro 2WD |
| Nebraska Tractor Test 1502 | |||
| |||
| Nebraska Tractor Test 1502 | |
| Diesel 12/4 gear 2WD October 17 - 31, 1983 Link: Nebraska Tractor Test 1502 file | |
| PTO performance | |
| Power at rated engine speed | 23.88 hp 17.8 kW |
| Fuel use | 1.9 gal/hour 7.2 l/hour |
| Power at rated PTO speed | 22.19 hp 16.5 kW |
| Fuel use | 1.7 gal/hour 6.4 l/hour |
| Drawbar performance | |
| Max power | 19.98 hp 14.9 kW |
| Fuel use | 1.8 gal/hour 6.8 l/hour |
| Gear 3-3 used for power test. | |
| Max pull | 2,700 lbs 1224 kg |
| Gear 2-3 used for pull test. | |
| Nebraska Tractor Test 1503 | |||
| |||
| Nebraska Tractor Test 1503 | |
| Diesel 12/4 synchro 2WD October 17 - 31, 1983 Link: Nebraska Tractor Test 1503 file | |
| PTO performance | |
| Power at rated engine speed | 23.79 hp 17.7 kW |
| Fuel use | 1.9 gal/hour 7.2 l/hour |
| Power at rated PTO speed | 22.34 hp 16.7 kW |
| Fuel use | 1.7 gal/hour 6.4 l/hour |
| Drawbar performance | |
| Max power | 20.48 hp 15.3 kW |
| Fuel use | 1.9 gal/hour 7.2 l/hour |
| Gear 3-3 used for power test. | |
| Max pull | 2,680 lbs 1215 kg |
| Gear 2-3 used for pull test. | |
