Ford FW-60
| | 1977 - 1982 |
| FW Series | | Four-wheel Drive (4WD) tractor | | Steiger built |
|
Series map:
FW-40
FW-60
295.0hp
335.0hp
| Production |
| Distributor | Ford
|
| Manufacturer | Steiger
|
| Four-wheel Drive (4WD) tractor |
| Built in Fargo, North Dakota, USA |
| Original price was $99,394 in 1982 |
| Ford FW-60 Power |
| Engine (gross) | 335 hp
249.8 kW
|
| Drawbar (claimed) | 260 hp
193.9 kW
|
| PTO (claimed) | 57 hp (540 RPM)
42.5 kW
|
| | 105 hp (1000 RPM)
78.3 kW
|
| Drawbar (tested) | 270.87 hp
202.0 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Final drives | outboard planetary
|
| Articulated power steering |
| Hydraulic dry disc brakes |
| Cab standard with air-conditioning. |
| Capacity |
| Fuel | 225 gal
851.6 L
|
| Hydraulic system | 25 gal
94.6 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 25 gal
94.6 L
|
| Pressure | 2250 psi
155.1 bar
|
| Valves | 4 or 5
|
| Pump flow | 30.1 gpm
113.9 lpm
|
| SCV flow | 20 gpm
75.7 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Rear lift (at 24"/610mm) | 12500 lbs
5670 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent *Optional. Hydrostatic-driven PTO
|
| Rear PTO Type | 540/1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 90
|
| Batteries | 4
|
| Battery CCA | 475 *Each
|
| Battery volts | 12
|
| References |
 |
| 4-wheel drive tractors published in 1977, by Ford |
