Allis Chalmers 5015
| | 1982 - 1985 |
| Sub-Compact Utility tractor | | Hinomoto built |
|
Series map:
5015
5020
18.0hp
25.0hp
| Production |
| Distributor | Allis Chalmers
|
| Manufacturer | Hinomoto
|
| Sub-Compact Utility tractor |
| Built in Osaka, Japan |
| Original price was $6,549 in 1985 |
| Variants |
| 9518 | similar Simplicity model
|
| Allis Chalmers 5015 Power |
| Engine | 18 hp
13.4 kW
|
| PTO (claimed) | 15 hp
11.2 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | mechanical rear
|
| Manual steering |
| Two post ROPS. Optional ROPS canopy. |
| Capacity |
| Fuel | 3.7 gal
14.0 L
|
| Hydraulic system | 4.5 gal
17.0 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 4.5 gal
17.0 L
|
| Valves | 0 or 1
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Power Take-off (PTO) |
| Rear PTO | continuous
|
| Rear PTO Type | 540 (1.375)
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| 1983 Lawn and Garden Line published by Allis-Chalmers |
| 1984 Lawn and Garden Line published by Allis-Chalmers |
| 1985 Lawn and Garden Line published by Allis-Chalmers |
| 5000 Series Attachments published in 1984, by Allis Chalmers |
| Compact diesels enter new dimensions published in 1983, by Allis Chalmers |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on November 15, 2023 |
