John Deere 8570



John Deere 8570 tractor photo
1993 - 1996
8070 Series
Four-wheel Drive (4WD) tractor
Series map:
8570
8770
250.0hp
300.0hp
Production
ManufacturerJohn Deere
Four-wheel Drive (4WD) tractor
Built in Waterloo, Iowa, USA
Original price was $96,000 in 1996
John Deere 8570 Engine
John deere 7.6L 6-cyl diesel
Engine details ...
John Deere 8570 Transmissions
12-speed partially synchronized
24-speed two-speed power shift
Transmission details ...
John Deere 8570 Power
Engine (gross)250 hp
186.4 kW
PTO (claimed)205 hp
152.9 kW
Drawbar (tested)191.59 hp
142.9 kW
PTO (tested)208.21 hp
155.3 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Steeringhydrostatic power
Hydraulic wet discs brakes
Sound-Gard cab standard.
Photos
No photos of the John Deere 8570 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel220 gal
832.7 L
Hydraulic system38 gal
143.8 L
Hydraulics
Typeclosed center pressure compensated
Capacity38 gal
143.8 L
Pressure2530 psi
174.4 bar
Rear valves3 to 5
Pump flow44.8 gpm
169.6 lpm
SCV flow33.3 gpm
126.0 lpm
Tractor hitch
Rear Type3 (optional)
Controldraft sensing
Rear lift14,980 lbs
6794 kg
Power Take-off (PTO)
Rear PTOindependent (optional)
Clutchhydraulic wet disc
Rear PTO Type1000 (1.75)
Dimensions & Tires
Wheelbase134 inches
340 cm
Weight29564 to 32100 pounds
Front tire24.5R-32
Rear tire24.5R-32
Full dimensions and tires ...
8570 Serial Number Location
John Deere 8570 serial number location
Left side of tractor hinge.
8570 Serial Numbers
19931001
19941551
19952595
19963001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Batteries2
Battery CCA925
Battery volts12
References
8570 references literature
250- to 400-HP 70 Series Tractors published in 1995, by John Deere
