Tractor Tests | |
OECD 1520: diesel 12-speed 4WD | |
OECD 1520: diesel 16-speed 4WD |
OCED Tractor Test 1520 | |||
|
OCED Tractor Test 1520 | |
Diesel 12-speed 4WD December 1993 - April 1994, Link: OCED Tractor Test 1520 file | |
PTO performance | |
Max power | 90.1 hp 67.2 kW |
Fuel use | 4.7 gal/hour 17.8 l/hour |
Power at rated engine speed | 86.8 hp 64.7 kW |
Fuel use | 4.8 gal/hour 18.2 l/hour |
Power at rated PTO speed | 88.5 hp 66.0 kW |
Fuel use | 4.8 gal/hour 18.2 l/hour |
Drawbar performance | |
Max power | 71.1 hp 53.0 kW |
Fuel use | 4.8 gal/hour 18.2 l/hour |
Gear 3B used for power test. | |
Max pull | 11895 lbs 5395 kg |
Gear 1B used for pull test. |
OCED Tractor Test 1520 | |||
|
OCED Tractor Test 1520 | |
Diesel 16-speed 4WD December 1993 - April 1994, Link: OCED Tractor Test 1520 file | |
PTO performance | |
Max power | 87.7 hp 65.4 kW |
Fuel use | 4.7 gal/hour 17.8 l/hour |
Power at rated engine speed | 85.2 hp 63.5 kW |
Fuel use | 4.9 gal/hour 18.5 l/hour |
Power at rated PTO speed | 86.1 hp 64.2 kW |
Fuel use | 4.8 gal/hour 18.2 l/hour |
Drawbar performance | |
Max power | 73.2 hp 54.6 kW |
Fuel use | 4.8 gal/hour 18.2 l/hour |
Gear 1C used for power test. | |
Max pull | 12415 lbs 5631 kg |
Gear 4A used for pull test. |
