Tractor Tests | |
OECD 1524: diesel 12-speed 4WD | |
OECD 1524: diesel 16-speed 4WD |
OCED Tractor Test 1524 | |||
|
OCED Tractor Test 1524 | |
Diesel 12-speed 4WD January 1994 - June 1994, Link: OCED Tractor Test 1524 file | |
PTO performance | |
Max power | 79.8 hp 59.5 kW |
Fuel use | 4.4 gal/hour 16.7 l/hour |
Power at rated engine speed | 77.6 hp 57.9 kW |
Fuel use | 4.5 gal/hour 17.0 l/hour |
Power at rated PTO speed | 79.5 hp 59.3 kW |
Fuel use | 4.5 gal/hour 17.0 l/hour |
Drawbar performance | |
Max power | 62.5 hp 46.6 kW |
Fuel use | 4.4 gal/hour 16.7 l/hour |
Gear 1C used for power test. | |
Max pull | 8590 lbs 3896 kg |
Gear 1B used for pull test. |
OCED Tractor Test 1524 | |||
|
OCED Tractor Test 1524 | |
Diesel 16-speed 4WD June 1994 - 1994, Link: OCED Tractor Test 1524 file | |
PTO performance | |
Max power | 77.5 hp 57.8 kW |
Fuel use | 4.5 gal/hour 17.0 l/hour |
Power at rated engine speed | 76.0 hp 56.7 kW |
Fuel use | 4.4 gal/hour 16.7 l/hour |
Power at rated PTO speed | 77.5 hp 57.8 kW |
Fuel use | 4.5 gal/hour 17.0 l/hour |
Drawbar performance | |
Max power | 61.5 hp 45.9 kW |
Fuel use | 4.4 gal/hour 16.7 l/hour |
Gear 1C used for power test. | |
Max pull | 8480 lbs 3846 kg |
Gear 1B used for pull test. |
