John Deere 5400 Transmission


John Deere 5400 tractor photo
1992 - 1997
5000 Utility Series
Utility tractor
Series map:
5300
5400
5500
55.9hp
68.4hp
83.2hp
Transmission options
9-speed unsynchronized gear
9-speed partially synchronized
12-speed power shuttle
Transmission
TransmissionJohn Deere Collar Shift
Typeunsynchronized gear
Gears9 forward and 3 reverse
Clutchdry disc
Three gears (1-3), plus reverse, with three ranges (A-C). Tractor must be stopped, and clutch used, to shift gear or range.
Speeds
5400 Collar Shift unsynchronized gear speeds
Transmission
TransmissionJohn Deere Top-Shaft Synchronized
Typepartially synchronized
Gears9 forward and 3 reverse
Clutchdry disc
Three gears (1-3), plus reverse, in three ranges (A-C). Gear shifts are synchronized using the clutch. Tractor must be stopped to shift range.
Speeds
5400 Top-Shaft Synchronized partially synchronized speeds
Transmission
TransmissionJohn Deere TSS Reverser
Typepower shuttle
Gears12 forward and reverse
Clutchwet disc
Four gears (1-4) in three ranges (A-C) with left-hand reverser lever.
