Tractors > John Deere > 4960

John Deere 4960 Tests



John Deere 4960 tractor photo
1992 - 1994
4060 Series
Row-Crop tractor
Series map:
4760
4960
194.4hp*
222.2hp*
*Estimated engine power for comparison only.
OCED Tractor Test 1622
4960 fuel use from test 60
OCED Tractor Test 1622
Diesel Powershift 4WD
April 1 - June 1, 1989
Link: OCED Tractor Test 1622 file
PTO performance
Max power210.00 hp
156.6 kW
Fuel use10.9 gal/hour
41.3 l/hour
Power at rated engine speed202.73 hp
151.2 kW
Fuel use11.0 gal/hour
41.6 l/hour
Drawbar performance
Max power176.48 hp
131.6 kW
Fuel use11.1 gal/hour
42.0 l/hour
Gear 12 used for power test.
Max pull23,715 lbs
10757 kg
Gear 3 used for pull test.
