John Deere 2155 Transmission


John Deere 2155 tractor photo
1987 - 1992
55 Utility Series
Utility tractor
Series map:
2155
2355
55.0hp
64.0hp
Transmission options
8-speed non-synchronized
8-speed partially synchronized
16-speed partial power shift
8-speed power shuttle
Transmission
TransmissionJohn Deere Collar Shift (CST)
Typenon-synchronized
Gears8 forward and 4 reverse
Clutchdry disc
Four gears with two forward and one reverse range.
Transmission
TransmissionJohn Deere Top-Shaft Synchronized (TSS)
Typepartially synchronized
Gears8 forward and 4 reverse
Clutchdry disc
Four gears (1-4) with two ranges (I-II) and reverse range. Optional creeper range provides 12 forward and 8 reverse speeds.
Speeds
With 14.9-24 rear tires.
2155 Top-Shaft Synchronized (TSS) partially synchronized speeds
Transmission
TransmissionJohn Deere Hi-Lo Top-Shaft Synchronized (TSS)
Typepartial power shift
Gears16 forward and 8 reverse
Clutchdry disc
Adds a hydraulic high-low power shift to the basic TSS transmission.
Transmission
TransmissionJohn Deere Collar Shift Reverser
Typepower shuttle
Gears8 forward and reverse
Adds a hydraulic reverse to the CST transmission.
