Tractors > John Deere > 8650

John Deere 8650



John Deere 8650 tractor photo
1982 - 1988
8050 Series
Four-wheel Drive (4WD) tractor
Series map:
8450
8650
8850
225.0hp
290.0hp
370.0hp
Production
ManufacturerJohn Deere
Four-wheel Drive (4WD) tractor
Built in Waterloo, Iowa, USA
Original price was $97,562 in 1983
The 8650 was the middle model of John Deere's 50-series four-wheel drive tractors that were first available in 1982. Efficiency was the advertising focus, noting that these tractors could be used throughout the season, not simply for tillage. The 8650 was able to plant and cultivate 30-inch rows, and perform a variety of field operations with its draft-control hitch and full-power PTO.
John Deere 8650 Engine
John Deere 10.1L 6-cyl diesel
Engine details ...
John Deere 8650 Transmission
16-speed partial power shift
Transmission details ...
John Deere 8650 Power
Engine290 hp
216.3 kW
PTO (claimed)235 hp
175.2 kW
Drawbar (tested)219.93 hp
164.0 kW
PTO (tested)238.56 hp
177.9 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic front and rear
Articulated power steering
Hydraulic wet disc brakes
Sound-Gard cab with air-conditioning
Photos
John Deere 8650, front view.
John Deere 8650 photos...
Capacity
Fuel214 gal
810.0 L
Hydraulic system37.5 gal
141.9 L
Hydraulics
Typeclosed center constant-pressure
Capacity37.5 gal
141.9 L
Valves2 to 4
Pump flow32 gpm
121.1 lpm
Tractor hitch
Rear TypeIII/IIIN
Controllower-link draft sensing
Rear lift9260 lbs
4200 kg
Power Take-off (PTO)
Rear PTOindependent OptOptional
Clutchhydraulic wet disc
Rear PTO Type1000 (1.75)
Dimensions & Tires
Wheelbase125 inches
317 cm
Weight29320 to 30270 pounds
Front tire18.4-38
Rear tire18.4-38
Full dimensions and tires ...
John Deere 8650 attachments
blade
Attachment details ...
8650 Serial Numbers
Location:Serial number plate on the rear of the tractor.
19821500
19833000
19845001
19857001
19868001
19878501
19889001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps110
Batteries2
Battery CCA975
Battery volts6
References
8650 references literature
Loaders, Spreaders and Blades published in 1984, by John Deere
4-Wheel-Drive Tractors published in 1981, by John Deere
4-Wheel-Drive Tractors published in 1983, by John Deere
4-Wheel-Drive Tractors published in 1986, by John Deere
8450, 8650, 8850 Competition published in 1982, by John Deere
Agricultural Price List published in 1983, by John Deere
