John Deere 8450


John Deere 8450 tractor photo
1982 - 1988
8050 Series
Four-wheel Drive (4WD) tractor
Series map:
8450
8650
225.0hp
290.0hp
Production
ManufacturerJohn Deere
Four-wheel Drive (4WD) tractor
Built in Waterloo, Iowa, USA
Original price was $78,707 in 1983
The John Deere model 8450 was introduced, along with the 8650 and 8850, in 1982 as replacements for the 40-series four-wheel drive tractors. Efficiency was the focus of Deere's advertising for these tractor models. Deere promoted the ability of the 8450 to perform planting and cultivation work, the duals could be set to navigate 30-inch crop rows. The 8450 also had a full-power PTO available, along with Load-and-Depth control on the three-point hitch.
John Deere 8450 Engine
John Deere 7.6L 6-cyl diesel
Engine details ...
John Deere 8450 Power
Engine225 hp
167.8 kW
PTO (claimed)185 hp
138.0 kW
Drawbar (tested)173.52 hp
129.4 kW
PTO (tested)186.98 hp
139.4 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic front and rear
Articulated power steering
Power wet disc brakes
Sound-Gard cab with air-conditioning
Capacity
Fuel185 gal
700.2 L
Hydraulic system37.5 gal
141.9 L
Hydraulics
Typeclosed center constant-pressure
Capacity37.5 gal
141.9 L
Valves2 to 4
Pump flow32 gpm
121.1 lpm
Tractor hitch
Rear Type3/3N
Controllower-link draft sensing
Rear lift9,262 lbs
4201 kg
Power Take-off (PTO)
Rear PTOindependent OptOptional
Clutchhydraulic wet disc
Rear PTO Type1000 (1.75)
Dimensions & Tires
Wheelbase125 inches
317 cm
Weight27560 to 29150 pounds
Front tire18.4-34
Rear tire18.4-34
Full dimensions and tires ...
8450 Serial Numbers
Location:Serial number plate on the rear of the tractor.
19821000
19832000
19843501
19855001
19865501
19876001
19886501

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps110
Batteries2
Battery CCA800
Battery volts6
References
8450 references literature
Loaders, Spreaders and Blades published in 1984, by John Deere
4-Wheel-Drive Tractors published in 1981, by John Deere
4-Wheel-Drive Tractors published in 1983, by John Deere
4-Wheel-Drive Tractors published in 1986, by John Deere
8450, 8650, 8850 Competition published in 1982, by John Deere
Agricultural Price List published in 1983, by John Deere
