John Deere 2840 Transmission


John Deere 2840 tractor photo
1977 - 1979
Utility tractor
Series map:
2640
2840
77.8hp*
89.6hp*
*Estimated engine power for comparison only.
Transmission options
12-speed two-speed power shift
6-speed
Transmission
TransmissionHi-Lo
Typetwo-speed power shift
Gears12 forward and 6 reverse
Clutchdry disc
Three gears (1-3) in two ranges (I/II) plus reverse (R) range with a high/low power shift.
Speeds
With 18.4-34 rear tires.
2840 Hi-Lo two-speed power shift speeds
Transmission
Transmissionsliding gear
Gears6 forward and 3 reverse
