John Deere 4030
| | 1973 - 1977 |
| Generation II Series | | Row-Crop tractor |
|
Series map:
4030
4230
88.9hp*
111.1hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | John Deere
|
| Row-Crop tractor |
| Built in Waterloo, Iowa, USA |
| Total built | 15,690 (total)
|
| | 222 (gasoline)
|
| Original price was $17,721 in 1977 |
| Mechanical |
| Two-wheel drive |
| Final drives | planetary
|
| Differential lock | hydro-mechanical rear OptOptional
|
| Power steering |
| Differential hydraulic wet disc brakes |
| Open operator station. Optional four-post Roll-Gard ROPS. Optional Sound-Gard cab with heat and air-conditioning available. |
| Capacity |
| Fuel | 35 gal
132.5 L
|
| Hydraulic system | 13 gal
49.2 L
|
| Hydraulics |
| Type | closed center
|
| Capacity | 13 gal
49.2 L
|
| Valves | 1 to 3
|
| Pump flow | 23 gpm
87.1 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000 (1.375)
|
| 4030 Serial Number Location |
 |
| Serial number plate on the rear of the John Deere 4030, above the PTO shaft. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Batteries | 2
|
| Battery volts | 6
|
| References |
 |
| Tractors 80 to 150 hp published in 1975, by John Deere |
| Making you next tractor a John Deere has traditionally been a good investment published in 1975 |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on September 2, 2020 |
