Production | |
Manufacturer | John Deere |
Agricultural Crawler tractor | |
Built in Dubuque, Iowa, USA | |
Total built | 506 (total) |
  | 379 (gas) |
  | 127 (diesel) |
John Deere 1010C Engines | |
John Deere 1.9L 4-cyl gasoline | |
John Deere 2.4L 4-cyl diesel | |
Fuel tank | 12 gal 45.4 L |
Engine details ... |
John Deere 1010C Transmission | |
4-speed gear | |
Transmission details ... |
John Deere 1010C Power | |
PTO (claimed) | 35 hp 26.1 kW |
Plows | 4 |
Drawbar (tested) | 28.71 hp 21.4 kW |
PTO (tested) | 36.31 hp 27.1 kW |
Performance test details ... |
Mechanical | |
Drive | crawler |
Steering | multiple disc clutch and brake |
Mechancial contracting band brakes | |
Open operator station. |
Photos | |
John Deere 1010C photos... |
Tractor hitch | |
Rear Type | I OptOptional |
Power Take-off (PTO) | |
Rear PTO | transmission |
Rear PTO Type | 540 |
Dimensions & Tracks | |
Weight | 7,580 lbs 3438 kg |
12-inch tracks | |
Full dimensions and tracks ... |
1010C Serial Numbers | |
1960 | 10001 |
1961 | 13692 |
1962 | 23630 |
1963 | 32188 |
1964 | 43900 |
1965 | 53722 |
Final | 57312 |
FAQ: How to read a serial number table. |
Electrical | |
Ground | positive |
Batteries | 1 (gas) |
  | 2 (diesel) |
Battery volts | 12 |
References | |
The John Deere 10 Series New Generation Tractors published in 2004, by Hain Publishing | |
Ten Ten Agricultural Crawler published in 1965, by John Deere | |
Tractors 1918-1976 published by John Deere* | |
Modern Farming published in 1962, by John Deere | |
Modern Farming published in 1965, by John Deere | |
*Publication contains known errors. |
