John Deere 8010
1960 Four-wheel Drive (4WD) tractor
Production Manufacturer John Deere
Four-wheel Drive (4WD) tractor Built in Waterloo, Iowa, USA Total built 100
Original price was $30,000 in 1960 Due to transmission issues, the John Deere 8010s were returned to the factory and converted into 8020s. One 8010 escaped the recall and is currently in the Keller collection.
John Deere 8010 Power Engine 215 hp160.3 kW
Drawbar (claimed) 150 hp111.9 kW
Mechanical Four-wheel drive Articulated power steering Pneumatic drum brakes Open operator station.
Photos No photos of the John Deere 8010 are currently available. To submit yours, email it to Peter@TractorData.com . Photos may only be used with the permission of the original photographer.
Capacity Fuel 106 gal401.2 L
Hydraulic system 25 gal94.6 L
Hydraulics Capacity 25 gal94.6 L
Pump flow 40 gpm151.4 lpm
60 gpmOpt Optional 227.1 lpm
Electrical Charging system generator
Charging volts 24
References The John Deere 10 Series New Generation Tractors published in 2004, by Hain Publishing New John Deere 8010 Diesel published in 1960 Operator's Manual 8010 Diesel Tractor (OM-R30814) published in 1960 Tractors 1918-1976 published by John Deere* Modern Farming published in 1962, by John Deere *Publication contains known errors.
