Tractors > Allis Chalmers > D14

Allis Chalmers D14 Tests



Allis Chalmers D14 tractor photo
1957 - 1960
D Series
Row-Crop tractor
Series map:
D14
37.8hp*
*Estimated engine power for comparison only.
Tractor Tests
NTTL 623: gasoline 8-speed 2WD
NTTL 645: LP gas 8-speed 2WD
Nebraska Tractor Test 623
D14 fuel use from test 623
Nebraska Tractor Test 623
Gasoline 8-speed 2WD
June 1 - 7, 1957
Link: Nebraska Tractor Test 623 file
Belt power (max)34.08 hp
25.4 kW
Belt fuel use (max)3.0 gal/hour
11.4 l/hour
Drawbar performance
Max power30.91 hp
23.0 kW
Gear 3 used for power test.
Max pull4,847 lbs
2198 kg
Gear 1D used for pull test.
Nebraska Tractor Test 645
D14 fuel use from test 645
Nebraska Tractor Test 645
LP gas 8-speed 2WD
April 1 - 12, 1958
Link: Nebraska Tractor Test 645 file
Belt power (max)31.86 hp
23.8 kW
Belt fuel use (max)3.7 gal/hour
14.0 l/hour
Drawbar performance
Max power28.67 hp
21.4 kW
Gear 3D used for power test.
Max pull5,023 lbs
2278 kg
Gear 1D used for pull test.
