Tractors > John Deere > 500C backhoe-loader

John Deere 500C



John Deere 500C tractor photo
1971 - 1982
Backhoe loader tractor
Series map:
500C
83.0hp
Production
ManufacturerJohn Deere
Backhoe loader tractor
John Deere 500C Engine
John Deere 4.4L 4-cyl diesel
Engine details ...
John Deere 500C Transmissions
8-speed gear
8-speed full power shift
Transmission details ...
John Deere 500C Power
Engine (gross)83 hp
61.9 kW
Engine (net)80 hp
59.7 kW
Mechanical
Two-wheel drive
Final drivesinboard planetary
Power steering
Hydraulic wet disc brakes
Open operator station. Four-post ROPS available. Cab available with heater.
Photos
No photos of the John Deere 500C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel34 gal
128.7 L
Hydraulic system21.5 gal (power shift)
81.4 L
 18.5 gal (gear)
70.0 L
Hydraulics
Typeclosed center
Capacity21.5 gal (power shift)
81.4 L
 18.5 gal (gear)
70.0 L
Pressure2000 psi
137.9 bar
Total flow28.5 gpm
107.9 lpm
Dimensions & Tires
Weight15400 lbs
6985 kg
Front tire8.25-16
Rear tire16.9-28
Full dimensions and tires ...
Backhoe & Loader
Dig depth190 inches
482 cm
Dump angle60 inches
152 cm
Loader/Backhoe details ...
Electrical
Charging systemalternator
Batteries2
Battery volts12
References
500C references literature
Utility Purchasing Guide published in 1972, by John Deere
Utility Purchasing Guide published in 1973, by John Deere
Utility Purchasing Guide published in 1978, by John Deere
Utility Purchasing Guide published in 1979, by John Deere
Utility Equipment Purchasing Guide published in 1981, by John Deere
