Production | |
Manufacturer | J.I. Case |
Backhoe loader tractor |
J.I. Case 590 Super L Engine | |
Case 3.9L 4-cyl diesel | |
Engine details ... |
J.I. Case 590 Super L Transmission | |
4-speed power shuttle | |
Transmission details ... |
J.I. Case 590 Super L Power | |
Engine (gross) | 95 hp 70.8 kW |
Engine (net) | 88 hp 65.6 kW |
Mechanical | |
Drive | 4x2 2WD: 4x4 MFWD 4WD |
Power steering |
Capacity | |
Fuel | 31.4 gal 118.8 L |
Hydraulic system | 33 gal 124.9 L |
Hydraulics | |
Type | open center |
Capacity | 33 gal 124.9 L |
Pressure | 2950 psi 203.4 bar |
Pump flow | 31.5 gpm 119.2 lpm |
  | 11 gpm 41.6 lpm |
Total flow | 42.5 gpm 160.9 lpm |
Dimensions & Tires | |
2WD Wheelbase | 84 inches 213 cm |
4WD Wheelbase | 84.5 inches 214 cm |
Weight | 15396 to 17130 pounds |
Front tire | 14.5x16.1 |
Rear tire | 21Lx24 |
Full dimensions and tires ... |
Backhoe & Loader | |
Dig depth | 191 inches 485 cm |
Dump angle | 45 inches 114 cm |
Loader/Backhoe details ... |
Electrical | |
Charging system | alternator |
Charging amps | 65 |
Battery CCA | 685 |
Battery volts | 12 |
References | |
Loader/Backhoe 590 Super L published in 1996, by J.I. Case |
