J.I. Case 680L Construction King
|
|
| Production | |
| Manufacturer | J.I. Case |
| Backhoe loader tractor | |
| J.I. Case 680L Engine | |
| J.I. Case 5.9L 6-cyl diesel | |
 Engine details ... |
| J.I. Case 680L Transmission | |
| 3-speed power shift | |
 Transmission details ... |
| J.I. Case 680L Power | |
| Engine (gross) | 101 hp 75.3 kW |
| Engine (net) | 90 hp 67.1 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | outboard planetary |
| Steering | hydrostatic power |
| Wet disc brakes | |
| ROPS canopy. Optional cab with available air-conditioning. | |
| Photos | |
| No photos of the J.I. Case 680L are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 43 gal 162.8 L |
| Hydraulic system | 14.2 gal (reservoir) 53.7 L |
| Hydraulics | |
| Type | open center |
| Capacity | 14.2 gal (reservoir) 53.7 L |
| Pump flow | 25.7 gpm 97.3 lpm |
| 18.7 gpm 70.8 lpm | |
| Total flow | 44.4 gpm 168.1 lpm |
| Steering flow | 18.7 gpm 70.8 lpm |
| Steering press. | 2000 psi 137.9 bar |
| Dimensions & Tires | |
| Wheelbase | 87 inches 220 cm |
| Weight | 18218 to 20398 pounds |
| Front tire | 11x16 |
| Rear tire | 19.5x24 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 198 inches 502 cm |
| Dump angle | 45 inches 114 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 65 |
| Batteries | 2 |
| Battery CCA | 680 |
| Battery volts | 12 |
| References | |
 | |
| Utility Equipment published in 1988, by J.I. Case |
