| | 1978 - 1984 |
| Backhoe loader tractor |
|
Series map:
555
755
57.0hp
97.0hp
| Transmission options |
| 6-speed |
| 4-speed torque converter |
| Transmission |
| Transmission | Manual-reversing
|
| Gears | 6 forward and 4 reverse
|
| Oil capacity | 12.7 qts
12.0 L
|
| Speeds |
| With 16.9x24 rear tires. |
|
| Transmission |
| Type | torque converter
|
| Gears | 4 forward and reverse
|
| Oil capacity | 19 qts
18.0 L
|
| Torque converter with stall at 2050 engine rpm and a multiplication ratio of 2.78-to-1. |
| Speeds |
| With 16.9x24 rear tires. |
|
