Ford 555 Transmission


Ford 555 tractor photo
1978 - 1984
Backhoe loader tractor
Series map:
555
755
57.0hp
97.0hp
Transmission options
6-speed
4-speed torque converter
Transmission
TransmissionManual-reversing
Gears6 forward and 4 reverse
Oil capacity12.7 qts
12.0 L
Speeds
With 16.9x24 rear tires.
555 Manual-reversing  speeds
Transmission
Typetorque converter
Gears4 forward and reverse
Oil capacity19 qts
18.0 L
Torque converter with stall at 2050 engine rpm and a multiplication ratio of 2.78-to-1.
Speeds
With 16.9x24 rear tires.
555  torque converter speeds
