Power King 1614
|
|
| Production | |
| Manufacturer | Power King (a part of Engineering Products Company) |
| Garden tractor | |
| Built in Waukesha, Wisconsin, USA | |
| Power King 1614 Engine | |
| 14HP Kohler 512cc 1-cyl gasoline | |
| Fuel tank | 8.25 gal 31.2 L |
 Engine details ... | |
| Power King 1614 Transmission | |
| 4-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Final drives | spur bull gears |
| Steering | manual |
| Open operator station. | |
| Photos | |
| No photos of the Power King 1614 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | 0 OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Rear PTO Type | 2000 |
| Front PTO | independent |
| Clutch | electro-magnetic |
| Dimensions & Tires | |
| Wheelbase | 57 inches 144 cm |
| Weight | 979 lbs 444 kg |
| Front tire | 8.0-10 |
| Rear tire | 8.0-16 |
 Full dimensions and tires ... | |
| Power King 1614 attachments | |
| 48" mid-mount mower deck | |
| 60" mid-mount mower deck | |
| snowblower | |
| blade | |
| front-end loader | |
 Attachment details ... |
| 1614 Serial Numbers | |
| Location: | Serial number decal on dashboard. |
| Electrical | |
| Ground | negative |
| Charging amps | 15 |
| Battery volts | 12 |
| Battery AH | 45 |
| References | |
 | |
| Owner's Manual for 1600/2400 Series Tractors (98-7171) published in 1984 | |
| Power King published in 1987, by Engineering Products Co. |
