Tractors > Caterpillar > D5B SA Special Application

Caterpillar D5B SA Special Application



Caterpillar D5B SA Special Application tractor photo
1977 - 1985
Agricultural Crawler tractor
Series map:
D5B SA
D6D SA
120.0hp
165.0hp
Production
ManufacturerCaterpillar
Agricultural Crawler tractor
Original price was $67,760 in 1985
Caterpillar D5B SA Engine
Caterpillar 10.5L 6-cyl diesel
Engine details ...
Caterpillar D5B SA Transmission
6-speed gear
Transmission details ...
Caterpillar D5B SA Power
Engine (net)120 hp
89.5 kW
Drawbar (claimed)90 hp
67.1 kW
Mechanical
Drivecrawler
Photos
No photos of the Caterpillar D5B SA are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel74 gal
280.1 L
Hydraulic system6 gal
22.7 L
Hydraulics
Typeopen center
Capacity6 gal
22.7 L
Pressure2000 psi
137.9 bar
Pump flow23 gpm
87.1 lpm
Dimensions & Tracks
Weight22900 to 23320 pounds
18-inch tracks
Full dimensions and tracks ...
Electrical
Charging systemalternator
Charging amps35
Battery volts12
References
D5B SA Special Application references literature
Track-Type Tractors published in 1980, by Caterpillar
Compact Sales Kit published in 1985, by Caterpillar
Tracteurs Caterpillar d4E, d5B, D6D, D7G Applications Speciales published in 1980
Special Application Tractors published in 1982, by Caterpillar
Puissance variable Travail plus rentable published in 1985, by Caterpillar
D5B Special Application published in 1980, by Caterpillar
D5B SA Tractor Variable Horsepower published by Caterpillar
Implement Matching for Cat Tillage Tractors published in 1983, by Caterpillar
