Tractors > Caterpillar > D3B SA Special Application

Caterpillar D3B SA Special Application

1985 - 1987

Agricultural Crawler tractor

Series map:

D3C SA↑ 1987-1991

D3B SA

101.0hp

Production
Manufacturer	Caterpillar
Agricultural Crawler tractor

Caterpillar D3B SA Engine
Caterpillar 5.2L 4-cyl diesel
Engine details ...

Caterpillar D3B SA Transmission
5-speed gear
Transmission details ...

Caterpillar D3B SA Power
Engine (net)	101 hp 75.3 kW
Drawbar (claimed)	81 hp 60.4 kW

Mechanical
Drive	crawler
Four-post ROPS.

Photos
No photos of the Caterpillar D3B SA are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.

Capacity
Fuel	54 gal 204.4 L
Hydraulic system	15.1 gal 57.2 L

Hydraulics
Type	open center
Capacity	15.1 gal 57.2 L
Pressure	2500 psi 172.4 bar
Pump flow	14 gpm 53.0 lpm

Dimensions & Tracks
Weight	13314 to 13846 pounds
12-inch tracks
Full dimensions and tracks ...

Electrical
Charging system	alternator
Charging amps	55
Battery volts	12

References

D3B Special Application Track-type Tractor published in 1986, by Caterpillar
