John Deere BO Lindeman



John Deere BO Lindeman tractor photo
1936 - 1947
Two-Cylinder Letter Series
Standard-tread tractor
Series map:
BO Lindeman
20.6hp*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Standard-tread tractor
Built in Yakima, Washington, USA
Total built1645 (BO)
 29 (BR)
The Lindeman Power Equipment Company converted the John Deere BO (as well as the BR and GPO, in smaller quantities) into Lindeman Crawler units with the addition of a tracked undercarriage.
Variants
Btricycle front axle
BRfixed front axle
BOOrchard
BNnarrow row-crop
BIindustrial tractor
BO Lindemancrawler
John Deere BO Lindeman Engines
John Deere 2.4L 2-cyl all fuel
John Deere 2.9L 2-cyl all fuel
Fuel tank13.5 gal
51.1 L
Aux. fuel1 gal
3.8 L
Engine details ...
John Deere BO Lindeman Transmission
4-speed gear
Transmission details ...
John Deere BO Lindeman Power
Drawbar (claimed)16.16 hp
12.1 kW
Belt (claimed)18.53 hp
13.8 kW
Plows2 *12-inch
Mechanical
Drivecrawler
Manual steering
Open operator station.
Photos
John Deere BO Lindeman
John Deere BO Lindeman photos...
Power Take-off (PTO)
Rear PTOtransmission
Rear PTO Type540 (1.125)
Engine RPM554@1150
Dimensions & Tracks
Weight4420 lbs
2004 kg
10-inch tracks
Full dimensions and tracks ...
BO Lindeman Serial Numbers
Location:BR/BO serial numbers shown. Lindeman Crawlers did not have separate serial numbers.
1936325000
1937326655
1938328111
1939329000
1940330633
1941332039
1942332427
1943332780
1944333156
1945334219
1946335642
1947336746
Final337345

FAQ: How to read a serial number table.
Links
Lindeman Archives: history and literature about Lindeman
Belt Pulley
Diameter10.625 inches
26 cm
Width6 inches
15 cm
RPM1150
Speed3200 ft/min
975.36 meters/min
Electrical
Groundpositive
Charging systemDelco generator
Battery volts6
References
BO Lindeman references literature
Tractors 1918-1976 published by John Deere*
*Publication contains known errors.
