Challenger MT645D
| | 2011 - 2013 |
| MT600D Series | | Row-Crop tractor |
|
Series map:
MT645D
MT655D
240.0hp
265.0hp
| Production |
| Manufacturer | Challenger (a part of AGCO)
|
| Row-Crop tractor |
| Built in Jackson, Minnesota, USA |
| Original price was $263,455 in 2013 |
| Variants |
| 8650 | similar Massey Ferguson model
|
| Challenger MT645D Power |
| Engine (gross) | 240 hp
179.0 kW
|
| PTO (claimed) | 205 hp
152.9 kW
|
| Drawbar (tested) | 170.7 hp
127.3 kW
|
| PTO (tested) | 250.8 hp
187.0 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-hydraulic
|
| Steering | hydrostatic power
|
| Hydraulic wet disc brakes |
| Trailer brakes | pneumatic (optional)
|
| | hydraulic (optional)
|
| Cab standard with air-conditioning and OptiRide Plus hydraulic suspension AGCO System 150 (optional); AGCOMMAND (optional) |
| Photos |
| No photos of the Challenger MT645D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 167 gal
632.1 L
|
| Exhaust fluid (DEF) | 16 gal
60.6 L
|
| Hydraulic system | 29.1 gal
110.1 L
|
| Hydraulics |
| Type | closed center load sensing (CCLS)
|
| Capacity | 29.1 gal
110.1 L
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 4 to 6
|
| SCV flow | 26.4 gpm
99.9 lpm
|
| Total flow | 46 gpm
174.1 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Rear lift | 22760 lbs
10323 kg
|
| Front Hitch | III (optional)
|
| Front lift (at ends) | 11000 lbs
4989 kg
|
| Drawbar | Cat. 3
|
| | Cat. 3 Heavy-Duty (optional)
|
| | Cat. 4 (optional)
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 1000/1000E (1.75)
|
| | 540E/1000/1000E (optional)
|
| Engine RPM | 540E@1577
|
| | 1000E@1605
|
| | 1000@1970
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 240
|
| Batteries | 2
|
| Battery volts | 12
|
| References |
 |
| Challenger MT600D Series published in 2011, by AGCO |
