Challenger MT475D
|
|
| Production | |
| Manufacturer | Challenger (a part of AGCO) |
| Utility tractor | |
| Variants | |
| 6614 | similar Massey Ferguson model |
| Challenger MT475D Engine | |
| AGCO Power 4.9L 4-cyl diesel | |
| Fuel tank | 64 gal 242.2 L |
| Exhaust fluid (DEF) | 9.2 gal 34.8 L |
 Engine details ... | |
| Challenger MT475D Transmission | |
| continuously variable transmission (CVT) | |
 Transmission details ... |
| Challenger MT475D Power | |
| Engine (gross) | 130 hp 96.9 kW |
| PTO (claimed) | 100 hp 74.6 kW |
| Drawbar (tested) | 80.8 hp 60.3 kW |
| PTO (tested) | 123.0 hp 91.7 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostatic power |
| Wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Challenger MT475D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load sensing (CCLS) |
| open center optional | |
| Valves | 2 to 4 |
| SCV flow | 15 gpm (open center) 56.8 lpm |
| -unknown- | |
| 29 gpm (CCLS) 109.8 lpm | |
| Tractor hitch | |
| Rear Type | III/II |
| Control | electronic lower link draft sensing |
| Rear lift (at 24"/610mm) | 11400 lbs 5171 kg |
| Drawbar | Cat. 2 |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| 540/540E/1000 | |
| 540/540E/1000/1000E | |
| Dimensions & Tires | |
| Wheelbase | 105 inches 266 cm |
| Weight | 12500 lbs 5670 kg |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 240 (2x 120) |
| 350 (2x 175) | |
| Batteries | 2 |
| Battery CCA | 600 |
| Battery volts | 12 |
| References | |
 | |
| Challenger MT400B Series published in 2013, by AGCO | |
| Challenger MT400B Series published in 2014, by AGCO |
