John Deere 7820
| | 2003 - 2006 |
| 7020 Series | | Row-Crop tractor |
|
Series map:
7720
7820
7920
128.9kw
141.0kw
153.0kw
| Production |
| Manufacturer | John Deere
|
| Row-Crop tractor |
| Built in Waterloo, Iowa, USA |
| John Deere 7820 Power |
| Engine (gross) | 189.1 hp
141.0 kW
|
| Engine (net) | 182.4 hp
136.0 kW
|
| Engine (max) | 199.8 hp
149.0 kW
|
| PTO (claimed) | 155 hp
115.6 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard. |
| Capacity |
| Fuel | 103.5 gal
391.7 L
|
| | 94.7 gal*With right step
358.4 L
|
| Hydraulic system | 28.5 gal
107.9 L
|
| Hydraulics |
| Type | closed center pressure-flow compensating (PFC)
|
| Capacity | 28.5 gal
107.9 L
|
| Pressure | 3046 psi
210.0 bar
|
| Valves | 7
|
| Pump flow | 32 gpm
121.1 lpm
|
| SCV flow | 30 gpm
113.6 lpm
|
| Tractor hitch |
| Rear Type | 3/3N
|
| Rear lift | 10050 lbs
4558 kg
|
| | 14000 lbsOptOptional
6350 kg
|
| Front Hitch | optional
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet discs
|
| Rear PTO Type | 540/1000 (1.375)
|
| Engine RPM | 540@1950
|
| | 1000@1950
|
| | 540E@1750
|
| | 1000E@1750
|
| Front PTO | independent OptOptional
|
| Front PTO Type | 540/1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 150
|
| Batteries | 2
|
| Battery CCA | 925
|
| Battery volts | 12
|
| References |
 |
| 7020 Series Tractors published in 2004, by John Deere |
