Challenger MT875C
| | 2009 - 2013 |
| MT800C Series | | Agricultural Crawler tractor |
|
Series map:
MT865C
MT875C
525.0hp
585.0hp
| Production |
| Manufacturer | Challenger (a part of AGCO)
|
| Agricultural Crawler tractor |
| Built in Jackson, Minnesota, USA |
| Original price was $473,854 in 2013 |
| Challenger MT875C Power |
| Engine (gross) | 585 hp
436.2 kW
|
| PTO (claimed) | 425 hp
316.9 kW
|
| Drawbar (tested) | 441.14 hp
329.0 kW
|
| PTO (tested) | 586.45 hp
437.3 kW
|
 Performance test details ... |
| Mechanical |
| Drive | crawler
|
| Steering | speed sensitive differential
|
| Hydraulic wet discs brakes |
| Trailer brakes | hydraulic OptOptional
|
| Cab standard with air-conditioning. |
| Hydraulics |
| Type | closed center pressure-flow compensated
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 4 to 6
|
| SCV flow | 36 gpm
136.3 lpm
|
| Total flow | 43.5 gpm
164.6 lpm
|
| | 59 gpmOptOptional
223.3 lpm
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000 (1.75)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 185
|
| Batteries | 4
|
| Battery CCA | 1000
|
| Battery volts | 12
|
| References |
 |
| Challenger MT800C/MT900C published in 2008, by AGCO |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on August 28, 2022 |
