Caterpillar D8L SA Special Application



Caterpillar D8L SA Special Application tractor photo
1984 - 1987
Agricultural Crawler tractor
Series map:
D7G SA
D8L SA
250.0hp
400.0hp
Production
ManufacturerCaterpillar
Agricultural Crawler tractor
Original price was $272,180 in 1985
Variants
D8Lbulldozer
Caterpillar D8L SA Engine
Caterpillar 18.0L 8-cyl diesel
Engine details ...
Caterpillar D8L SA Transmission
3-speed power shift
Transmission details ...
Caterpillar D8L SA Power
Engine400 hp
298.3 kW
Drawbar (claimed)335 hp
249.8 kW
Mechanical
Drivecrawler
Final drivesdouble-reduction planetary
ROPS. Cab available with air-conditioning.
Photos
No photos of the Caterpillar D8L SA are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel189 gal
715.4 L
Hydraulic system23.5 gal
88.9 L
Hydraulics
Typeload sensing
Capacity23.5 gal
88.9 L
Pressure2500 psi
172.4 bar
Valves4
Pump flow30 gpm
113.6 lpm
Dimensions & Tracks
Weight77692 to 80820 pounds
36-inch tracks
Full dimensions and tracks ...
Electrical
Charging systemalternator
Charging amps35
 50 OptOptional
Batteries2
Battery volts12
Battery AH172
References
D8L SA Special Application references literature
Special Application Tractors published in 1982, by Caterpillar
Implement Matching for Cat Tillage Tractors published in 1983, by Caterpillar
