John Deere 6510



John Deere 6510 tractor photo
1997 - 2001
6000 TEN Series
Row-Crop tractor
Series map:
6510
6610
78.3kw
85.0kw
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 6510 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank54.7 gal
207.0 L
Engine details ...
John Deere 6510 Transmission
24-speed four-speed power shift
Transmission details ...
John Deere 6510 Power
Engine105 hp
78.3 kW
PTO (claimed)92 hp
68.6 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockelectro-hydraulic wet disc
Power steering
Hydraulic wet disc brakes
TechCenter cab standard with air-conditioning.
Photos
John Deere 6510
John Deere 6510 photos...
Hydraulics
Typeclosed-center load sensing
Pressure2900 psi
200.0 bar
Valves4 OptOptional
Pump flow16.6 gpm
62.8 lpm
 25.4 gpmOptOptional
96.1 lpm
Tractor hitch
Rear TypeII/IIIN
Controlelectronic lower-link draft sensing
Rear Armstelescopic link ends
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@2143
 540E@1684
 1000@2208
Front PTOindependent
Clutchelectro-hydraulic wet disc
Front PTO Type1000 (1.375)
Engine RPM1000@2185
Dimensions & Tires
Wheelbase104.3 inches
264 cm
Weight10360 lbs
4699 kg
Front tire16.9R24
Rear tire18.4R38
Full dimensions and tires ...
John Deere 6510 attachments
front-end loader
Attachment details ...
6510 Serial Numbers
Location:Plate located on right side of main tractor frame.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
 115 OptOptional
Battery volts12
Battery AH154
 174 OptOptional
References
6510 references literature
6010 Series Tractors: 6 cylinder 77 kW to 110 kW published in 2002, by John Deere
Operator's Manual 6510, 6610, 6810 and 6910 Tractors (OMAL116300) published in 1999
