Tractors > Caterpillar > D7G SA Special Application

Caterpillar D7G SA Special Application

1980 - 1986

Agricultural Crawler tractor

Series map:

D7G SA

D8L SA

250.0hp

400.0hp

Production
Manufacturer	Caterpillar
Agricultural Crawler tractor
Original price was $166,210 in 1985

Variants
D7G	bulldozer

Caterpillar D7G SA Engine
Caterpillar 10.5L 6-cyl diesel
Engine details ...

Caterpillar D7G SA Transmission
6-speed gear
Transmission details ...

Caterpillar D7G SA Power
Engine	250 hp 186.4 kW
Drawbar (claimed)	200 hp 149.1 kW

Mechanical
Drive	crawler
ROPS. Cab available with air-conditioning.

Photos
No photos of the Caterpillar D7G SA are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.

Capacity
Fuel	155 gal 586.7 L
Hydraulic system	24 gal 90.8 L

Hydraulics
Type	open center
Capacity	24 gal 90.8 L
Pressure	2250 psi 155.1 bar
Valves	3
Pump flow	32 gpm 121.1 lpm

Dimensions & Tracks
Weight	39500 to 40700 pounds
22-inch tracks
Full dimensions and tracks ...

Electrical
Charging system	alternator
Battery volts	12

References

Tracteurs Caterpillar d4E, d5B, D6D, D7G Applications Speciales published in 1980
Special Application Tractors published in 1982, by Caterpillar
Implement Matching for Cat Tillage Tractors published in 1983, by Caterpillar
