Yanmar YM336
| | 1980 - 1991 |
| Compact Utility tractor |
|
Series map:
YM276
YM336
27.0hp
33.0hp
| Production |
| Manufacturer | Yanmar
|
| Compact Utility tractor |
| Built in Japan |
| Original price was $12,400 in 1991 |
| Variants |
| YM336 | 2WD
|
| YM336D | 4WD
|
| Yanmar YM336 Power |
| Engine (gross) | 33 hp
24.6 kW
|
| PTO (claimed) | 26.5 hp
19.8 kW
|
| Drawbar (tested) | 22.46 hp
16.7 kW
|
| PTO (tested) | 26.98 hp
20.1 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Mechanical drum brakes |
| Two-post ROPS. |
| Hydraulics |
| Type | open center
|
| Pressure | 2204 psi
152.0 bar
|
| Pump flow | 8.2 gpm
31.0 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position and draft control
|
| Rear lift (at ends) | 2116 lbs
959 kg
|
| Rear lift (at 24"/610mm) | 1450 lbs
657 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Clutch | overrunning dry disc
|
| Rear PTO Type | 540/1000 (1.375)
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| YFL Series Loaders published in 1987, by Yanmar |
| Sales Promotion Manual published in 1979, by Yanmar* |
| YM276/336 27 & 33 Horsepower Compact Tractors published in 1987, by Yanmar |
| *Publication contains known errors. |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on April 3, 2024 |
©2000-2024 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Yanmar YM336 photos...
