Kubota M95S
Series map:
M95S
M105S
95.0hp
105.0hp
| Production |
| Manufacturer | Kubota
|
| Variants |
| M95X | IntelliShift
|
| M95H | 2WD ROPS
|
| M95DS-F | 4WD ROPS
|
| M95DSC | 4WD cab
|
| Kubota M95S Power |
| Engine (net) | 95 hp
70.8 kW
|
| PTO (claimed) | 84 hp
62.6 kW
|
| Mechanical |
| Drive | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering | Hydrostatic power steering
|
| Wet disc brakes |
| Cab optional with heat and air-conditioning |
| Photos |
| No photos of the Kubota M95S are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Valves | 1 to 3
|
| Pump flow | 17.2 gpm
65.1 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift (at 24"/610mm) | 4,630 lbs
2100 kg
|
| | 7,490 lbs (optional)
3397 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540
|
| | 540/1000 (optional)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 45 (ROPS)
|
| | 60 (cab)
|
| | 80 (optional)
|
| Battery volts | 12
|
