Massey Ferguson 265
| | 1975 - 1983 |
| 200 Series | | Row-Crop tractor |
|
Series map:
255
265
275
55.6hp*
66.7hp*
74.4hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | Massey Ferguson
|
| Row-Crop tractor |
| Built in Detroit, Michigan, USA |
| Original price was $22,500 in 1983 |
| Massey Ferguson 265 Power |
| Drawbar (claimed) | 50 hp
37.3 kW
|
| PTO (claimed) | 60 hp
44.7 kW
|
| Drawbar (tested) | 50.38 hp
37.6 kW
|
| PTO (tested) | 60.73 hp
45.3 kW
|
 Performance test details ... |
| Mechanical |
| Two-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Differential mechanical dry disc brakes |
| Open operator station. Two-post ROPS optional. Cab optional. |
| Capacity |
| Fuel | 18.5 gal
70.0 L
|
| Hydraulic system | 8 gal
30.3 L
|
| Hydraulics |
| Capacity | 8 gal
30.3 L
|
| Pressure | 2300 psi
158.6 bar
|
| Valves | 0 to 2
|
| Pump flow | 10 gpm
37.9 lpm
|
| | 4.5 gpm (3-point)
17.0 lpm
|
| Total flow | 19.5 gpm
73.8 lpm
|
| Steering flow | 5 gpm
18.9 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Rear lift | 4100 lbs
1859 kg
|
| Power Take-off (PTO) |
| Rear PTO | live (two-stage clutch)
|
| | independent (optional)
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@1683
|
| 265 Serial Numbers |
| Location: | Below instrument panel
|
| 1974 | 9A202190
|
| 1975 | 9A207681
|
| 1976 | 9A232539
|
| 1977 | 9A254045
|
| 1978 | 9A276935
|
| 1979 | 9A296946
|
| 1980 | 9A326169
|
| 1981 | 9A339343
|
| 1982 | 9A350584
|
| 1983 | 9A354679
|
FAQ: How to read a serial number table.
|
| Electrical |
| Charging system | alternator
|
| Charging amps | 37
|
| Battery volts | 12
|
| Battery AH | 95
|
| References |
 |
| Loaders and Spreaders published in 1979, by Massey Ferguson |
| MF 255/265/275 Tractors published in 1975, by Massey Ferguson |
| MF 34-81HP Tractors published in 1980, by Massey Ferguson |
| MF 200 Series Tractors published in 1982, by Massey Ferguson |
| Complete Farm Machinery Guide published in 1976, by Massey Ferguson |
