Ford TW-15
|
|
| Production | |
| Manufacturer | Ford |
| Row-Crop tractor | |
| Built in Antwerp, Belgium | |
| Original price | $41,000 |
| Ford TW-15 Engine | |
| Ford 6.6L 6-cyl diesel | |
 Engine details ... |
| Ford TW-15 Transmissions | |
| 16-speed two-speed power shift | |
| 24-speed | |
 Transmission details ... |
| Ford TW-15 Power | |
| Engine (gross) | 140 hp 104.4 kW |
| Engine | 137 hp 102.2 kW |
| PTO (claimed) | 120 hp 89.5 kW |
| Drawbar (tested) | 105.89 hp 79.0 kW |
| PTO (tested) | 121.40 hp 90.5 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | hydraulic rear |
| Power steering | |
| Differential hydraulic wet disc brakes | |
| Two-post fixed ROPS. Cab optional with air-conditioning. | |
| Photos | |
 | |
 Ford TW-15 photos... | |
| Capacity | |
| Fuel | 58 gal 219.5 L |
| Hydraulic system | 18.25 gal 69.1 L |
| 23.8 gal (Series II) 90.1 L | |
| Hydraulics | |
| Type | open center *With closed-center remote valves. |
| Capacity | 18.25 gal 69.1 L |
| 23.8 gal (Series II) 90.1 L | |
| Pressure | 2500 psi 172.4 bar |
| Valves | 2 |
| Pump flow | 15.3 gpm 57.9 lpm |
| Total flow | 27.5 gpm 104.1 lpm |
| Steering flow | 4.2 gpm 15.9 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| III OptOptional | |
| Rear lift (at 24"/610mm) | 7150 lbs 3243 kg |
| 9450 lbs*With optional auxiliary ram. 4286 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Engine RPM | 540@1861 |
| 1000@1918 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 108 inches 274 cm |
| 4WD Wheelbase | 105 inches 266 cm |
| Weight | 11355 to 14300 pounds |
| Front tire | 10.00-16 |
| Rear tire | 18.4-38 |
 Full dimensions and tires ... | |
| Ford TW-15 attachments | |
| front-end loader | |
 Attachment details ... |
| TW-15 Serial Numbers | |
| Location: | Under forward right grill panel |
| 1983 | C694500 |
| 1984 | C707400 |
| 1985 | C732600 |
| 1986 | A915854 |
| 1987 | A917560 |
| 1988 | A919438 |
| 1989 | A922535 |
| 1990 | A925099 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 72 |
| Battery volts | 12 |
| Battery AH | 128 |
| References | |
 | |
| Farm Loaders published in 1988, by Ford | |
| Front-end Loaders published in 1989, by Ford | |
| Front-end Loaders published in 1992, by Ford | |
| Front-end Loaders published in 1995, by New Holland | |
| Tractor Buyer's Guide published in 1989, by Ford | |
| Sales Reference Guide published in 1986, by Ford | |
| TW Series Tractors published in 1987, by Ford | |
| TW Series Tractors Repair Manual (SE 4117) published in 1983 |
